AIRCRAFT
TAKEOFF WEIGHT (WITHOUT ACCESSORIES)
909g
MAX TAKEOFF WEIGHT
1100g
DIMENSIONS (L×W×H)
Folded: 214×91×84mm
Unfolded: 322×242×84mm
Unfolded+Spotlight: 322×242×114mm
Unfolded+Beacon: 322×242×101mm
Unfolded+Speaker: 322×242×140mm
Unfolded+RTK Module: 322x242x125mm
DIAGONAL DISTANCE
354 mm
MAX ASCENT SPEED
6 m/s (S-mode)
5 m/s (P-mode)
4 m/s (S-mode with accessories)
4 m/s (P-mode with accessories)
MAX DESCENT SPEED
5 m/s (S-mode)
4 m/s (P-mode)
3 m/s (S-mode with accessories)
3 m/s (P-mode with accessories)
MAX HORIZONTAL SPEED
16 m/s (S-mode)
5 m/s (P-mode)
5 m/s (S-mode with accessories)
5 m/s (P-mode with accessories)
MAX SERVICE CEILING ABOVE SEA LEVEL
5000 m
MAX FLIGHT TIME
31 minutes (measured while flying at 12 m/s in windless conditions)
MAX HOVER TIME
29 minutes (measured when flying in windless conditions)
MAX FLIGHT RANGE
18 km (measured while flying in windless conditions)
OPERATING TEMPERATURE RANGE
-20°C to 40°C
MAX WIND RESISTANCE
8.5-10.5 m/s (Scale 5)
MAX ANGLE OF BANK
35°(S-mode)
25°(P-mode)
MAX ANGULAR VELOCITY
200°/s
MAX PITCH ANGLE
-90° to +25°
SENSING SYSTEM
OBSTACLE SENSING RANGE
Forward, Backward, Left and Right: 0.8-30 m
Upward: 0.3-8 m
Downward: 0.5-11 m
Sides: 0.5-11 m
OPERATING ENVIRONMENT
Surfaces with clear patterns and adequate lighting (lux > 15)
Diffuse reflection surface with reflectivity > 20% (wall, tree, people, etc.)
CAMERA
SENSOR
1/2” CMOS, Effective pixels: 12 MP
LENS
FOV: 85°, 35 mm format equivalent: 24 mm
Aperture: f/2.8
Focus: 1 m to ∞
ISO RANGE
Video: 100-6400 (Auto) 100-6400 (Manual)
Photo: 100-6400 (Auto) 100-3200 (Manual)
SHUTTER SPEED
Electronic shutter: 8-1/8000s
MAX IMAGE SIZE
4000×3000 pixels
VIDEO RESOLUTION
4K: 3840×2160 @ 24/25/30/48/50/60fps
FHD: 1920×1080 @ 24/25/30/48/50/60/120fps
SUBSYSTEMS
Spotlight, Speaker, Beacon
REMOTE CONTROLLER
OPERATING FREQUENCY
2.400-2.4835 GHz; 5.725-5.850 GHz
MAX TRANSMISSION DISTANCE (UNOBSTRUCTED, FREE OF INTERFERENCE)
10 km (FCC), 6 km (CE), 6 km (SRRC), 6 km (MIC)
OPERATING TEMPERATURE RANGE
-10°C to 40°C
TRANSMISSION POWER (EIRP)
2.400-2.4835 GHz:
FCC: ≤26 dBm
CE: ≤20 dBm
SRRC: ≤20 dBm
MIC: ≤20 dBm
5.725-5.850 GHz:
FCC: ≤26 dBm
CE: ≤14 dBm
SRRC: ≤26 dBm
BATTERY
18650 lithium battery
OPERATING CURRENT/VOLTAGE
1800 mA ⎓ 3.83 V
SUPPORTED MOBILE DEVICE SIZE
Max length: 92 mm
SUPPORTED USB PORT TYPES
Lightning, Micro USB (Type-B), USB-C
INTELLIGENT FLIGHT BATTERY
CAPACITY
2250 mAh
VOLTAGE
7.7 V
MAX CHARGING VOLTAGE
8.8 V
BATTERY TYPE
LiPo 2S
ENERGY
17.32 Wh
NET WEIGHT
86.2g
CHARGING TEMPERATURE RANGE
5°C to 40°C
MAX CHARGING POWER
24W
CHARGER
INPUT
100-240 V, 50/60 Hz, 1A
OUTPUT
5V/3A 9V/2A 12V/1.5A
APP
VIDEO TRANSMISSION SYSTEM
OcuSync 2.0
NAME
DJI Fly
LATENCY (DEPENDING ON ENVIRONMENTAL CONDITIONS AND MOBILE DEVICE)
170-240 ms
MAX LIVE VIEW RESOLUTION
720p @ 30fps
MOBILE DEVICE SYSTEM REQUIREMENTS
iOS 10.0 or later Android 6.0 or later
